220V 3T Fast Sliding Gate Opener Heavy Duty Hospital PVC Coated

220V 3T Fast Sliding Gate Opener Heavy Duty Hospital PVC Coated

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G30F

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: Gate Motor Sliding Smart Open Style: Sliding
Color: Blue,Red,Black,White Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated, Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Shop,Garage Door
Usage: Garden Decoration,Dormitory,Hospital Size: Width 27cmX Height 32cm
Advantage: Powerful,Safety Alarm Lighting: Optional
High Light:

3T Fast Sliding Gate Opener

,

Fast Sliding Gate Opener PVC Coated

,

220V 3T automatic door gate opener

Product Description

Fast Ac 220v Single Phase 3000kg Heavy Duty Automatic Slide Gate Motors Commercial Use



The heavy duty sliding door operator with high speed has a manual unlocking mechanism to move the door in the event of a power outage, and the powerful three-phase self-ventilating gear motor with its oil bath gearbox guarantees intensive use.



The ultra-fast sliding door motor travel ensures your door will open and close faster than other motors on the market. This is especially useful for properties that are located on busy roads or need added security to quickly close the gates. This sliding door motor can move up to 24m/min.



             High Speed Heavy Duty Sliding Gate Motors G30  Commercial Use

Power Supply 220V +/- 10%, 50Hz- Single Phase
Power of motor 750W
Output Pinion 19 Tooth Mod 4
Operating Speed 24m/min
Motor Cooling Direct Drive Fan (1400RPM)
Ambient Temperature Range From-37'F (-35°C) to 149.F (+65'C)
Motor Thermal Protection Electronic
Maximum Gate length 20m
IPRating 44
Shipping Mass of Unit 19 kgs(- 42 Ibs)
Maximum Gate Mass 3000 kgs ( ~ 6615 lbs)



The ultra-fast sliding door motor travel ensures your door will open and close faster than other motors on the market. This is especially useful for properties that are located on busy roads or need added security to quickly close the gates. This sliding door motor can move up to 24m/min.

This 220v single voltage fast sliding gate motors could be equipped with extenal receiver with 400pcs remtoe controls or 800pcs for your gate motors, which is perfect choice for you who want to set lots of transmitters.



Galvanized steel gear rack for this driveway sliding gate openers is one of the necessary accessories;



Inside of sliding gate motors

220V 3T Fast Sliding Gate Opener Heavy Duty Hospital PVC Coated 0220V 3T Fast Sliding Gate Opener Heavy Duty Hospital PVC Coated 1



The gearbox is lubricated, and the coded remote control allows transmission of 30 to 50 meters. This sliding control panel supports photocell input to provide additional safety features, and limit switches can achieve reliable and accurate positioning. The shell is made of high-quality materials with high quality





FAQ





What is the input voltage for this gate motors ?

220V input voltage.



What is the Max weight of gate?

Max weight supporting is 3000kgs.



How many models do you have for sliding gate openers ?

G6,G8,G15,G20,G30



What is the frequncy of your remote control for this sliding gate motors?

Remote control models are 433Hz.



What is the longest remote control distance in meters?

Long range distance reach 100m.



How many gate motors can be controlled by a remote control?

4 gate motors for a remote control.



Is there a requirement for the MOQ?

One unit is available,but it is sample cost. For large quantity,Please negotiable with us.



What kind of payments do you support?

Payment<=5000USD, 100% T/T in advance. Payment>=10000USD, 30% T/T in advance ,balance against of copy of B/L.If you have another questions, pls feel free to contact us.



What is your warranty terms?

2 year warranty



How long is your delivery time?

For standard products, 10-25 days are available.
