Galvanized DC Sliding Gate Motor 110V 60Hz Single Phase 27X32cm

Galvanized DC Sliding Gate Motor 110V 60Hz Single Phase 27X32cm

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G5D

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: Sliding Gate Motor Manufacturers Open Style: Sliding
Color: Blue,Red,Black,Grey,Yellow Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated,Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Store,Farm
Usage: Community,Dormitory,Hospital Size: Width 27cmX Height 32cm
Advantage: Easy Entrance, Economical And Practical Alarm Lighting: Optional
High Light:

Galvanized DC Sliding Gate Motor

,

DC Sliding Gate Motor 110V 60Hz

,

110V 60Hz double sliding gate motor

Product Description

DC 24V With Battery 500kg Automatic Slide Gate Motors Home Use



24V version of the speed and position management and control system;

Proximity limit switches allow for accurate and safe installation in any environmental conditions;

Backup battery powered system, on-board unit (24V version) can be installed;

Built-in dual channel radio receiver

Gear Motor,

2x Remote Controls,

Safety Sensors,

Signal Lights,

Rack and Pinion;



                                                             G5D  Home Use

Power Supply 110V or 230V +/- 10%, 60Hz- Single Phase
Power of motor 150W
Output Pinion 19 Tooth Mod 4
Operating Speed 12m/min
Motor Cooling Direct Drive Fan (1400RPM)
Ambient Temperature Range From-37'F (-35°C) to 149.F (+65'C)
Motor Thermal Protection Electronic
Maximum Gate length 20m
IPRating 44
Shipping Mass of Unit 17.5 kgs(- 39 Ibs)
Maximum Gate Mass 1500 kgs ~ 2000 kgs (3308 lbs ~ 4410 lbs)



Limit Switch Type Magnet or Spring limit
Without Electricity Manual, Key Usage
Warranty Perriod 2 year
Extented Warranty Available





Sliding door motors up to 500kg in 24V versions;

Built-in control panel, built-in 433 MHZ and electromechanical or magnetic limit switch;

Lightweight gate motors and support standard sliding gate with 500kg;

Basic accessories is with galvanized steel gear rack and opinion,such as 12mm with mode 4;



Inside of DC sliding gate operators

Galvanized DC Sliding Gate Motor 110V 60Hz Single Phase 27X32cm 0Galvanized DC Sliding Gate Motor 110V 60Hz Single Phase 27X32cm 1



The gearbox is lubricated, and the coded remote control allows transmission of 30 to 50 meters. This sliding control panel supports photocell input to provide additional safety features, and limit switches can achieve reliable and accurate positioning. The shell is made of high-quality materials with high quality.





FAQ





What is the input voltage for this gate motors ?

110V input voltage.



What is the Max weight of gate?

Max weight supporting is 500kgs.



How many models do you have for sliding gate openers ?

G6,G8,G15,G20,G30



What is the frequncy of your remote control for this sliding gate motors?

Remote control models are 433Hz.



What is the longest remote control distance in meters?

Long range distance reach 100m.



How many gate motors can be controlled by a remote control?

4 gate motors for a remote control.



Is there a requirement for the MOQ?

One unit is available,but it is sample cost. For large quantity,Please negotiable with us.



What kind of payments do you support?

Payment<=5000USD, 100% T/T in advance. Payment>=10000USD, 30% T/T in advance ,balance against of copy of B/L.If you have another questions, pls feel free to contact us.



What is your warranty terms?

2 year warranty



How long is your delivery time?

For standard products, 10-25 days are available.
