2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board

2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G20AC

Payment & Shipping Terms:

Minimum Order Quantity: 10
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: 2500kg Automatic Sliding Gate Motor Open Style: Sliding
Color: Black Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated,Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Industrial,Shop,Garden
Usage: Hospital,House,Villa,Factory,Garden Decoration,Villa,Construction Site Size: Width 27cmX Height 32cm
Advantage: Safety, Convenient,Trustworthiness Alarm Lighting: Optional
High Light:

Aluminum Sliding Gate Operator

,

2500kg Heavy Duty Sliding Gate Opener

,

2500kg Sliding Gate Operator

Product Description

2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board



The 2500 kg all-in-one machine is built-in circuit board, the overall installation is more convenient, the maximum load is less than 2000 kg, and the price is affordable and cost-effective.

electric gate motors,sliding gate motor 2000kg,for electric gate motor price



Product Name Heavy duty sliding gate motor
Description G20AC
Power supply 220V+10% 50HZ
Power of motor 500W
Motor speed 1400r/min
Max weight of gate <2500Kg
Motor thermal protection 130℃
Environment temperature range -20℃ 55℃

high power sliding door opener industry gate operator oil hwavy industrial,high power sliding door opener industry gate operator
high power sliding door opener industry gate operator oil,sliding rolling gate opener,sliding door opener industry gate operator,large power sliding gate opener price,sliding automatic gate opener,for automatic sliding swing gate openers operators

2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board 0
2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board 12500kg Heavy Duty Sliding Gate Operator With Built-In Control Board 2
2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board 3

2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board 4

2500kg Heavy Duty Sliding Gate Operator With Built-In Control Board 5



Main Features

1) Stylish appearance design and built-in control panel, easy installation and extremely compact. No external controller or receiver is required.

2) Built-in limit switch to allow the motor to turn off after the cycle is complete.

3) Built-in manual override with 2 unique override keys provided in case of emergency or power failure.

4) The motor is constructed of all-metal gears for durability.

5) Soft start and slow stop.

6) Resistance sensitivity and automatic closing delay time are adjustable.

7) Stop/reverse when an obstacle is encountered during door opening/closing.

8) Reliable mechanical spring limit or magnetic limit is optional.

9) 12 months warranty, lifetime after-sale service.



Packaging Details: Standard Exporting Packing

Measurement of carton box: 34*28*42 cm

Weight : 20KG



FAQ:

Communication with customers:

1 The motor runs but the sliding gate operator doesn't work.

A: Check whether the clutch is closed.

2 The power indicator light doesn't flash and the key doesn't

react.

A: Check whether power is connected right.

B: Check whether the fusel is burned, it yes, please exchange it.

3 The opening and closing limit can not work.

A: Check whether the limit adjustment switch is installed right.

B: Check whether the limit iron is installed right. Adjust the

position of the limit iron.

4 Crash proof is not effective.

A: Check whether the connection of crash proof is correct.

B: Check whether the photocell is installed right.

C: Check whether the connection of the wire of the loop

detector is right .

5 When the gate just close up, it turns to open.

A: Check whether the voltage is normal.

B: If the crash proof equipment is installed, please check

whether it works well.

6 The remote control doesn't work

A: Check whether the battery is low. If yes, change it.

B: Check whether the code of the remote control is the same

with the code of the control panel.
