Remote Control AC 110v Gate Opener Electronic 2000kg Gate Mass

Remote Control AC 110v Gate Opener Electronic 2000kg Gate Mass

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G20

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: Remote Slide Gate Opener Open Style: Sliding
Color: Blue,Grey Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated,Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Park,School
Usage: Garden Decoration And Villa Size: Width 27cmX Height 32cm
Advantage: Strong, Easy Installation Alarm Lighting: Optional
High Light:

AC 110v Gate Opener

,

Remote Control 110v Gate Opener

,

2000kg remote control sliding gate opener

Product Description

Ac 110v 2000kg Automatic Sliding Gate Openers Residential Use



GATECH operators provide sliding door motors up to 2000kg in 220V and 110V versions. G20 automatic sliding gate operator is equipped with a built-in control panel, built-in 433 MHZ and electromechanical or magnetic limit switch.

Reliability and safety features enable the operator to maintain excellent quality.



                                                             G20  Residential use

Power Supply 110V +/- 10%, 60Hz- Single Phase
Power of motor 700W
Output Pinion 19 Tooth Mod 4
Operating Speed 12m/min
Motor Cooling Direct Drive Fan (1400RPM)
Ambient Temperature Range From-37'F (-35°C) to 149.F (+65'C)
Motor Thermal Protection Electronic
Maximum Gate length 20m
IPRating 44
Shipping Mass of Unt 17.5kg(-39 Ibs)
Maximum Gate Mass 1500-2000kgs (3307lbs~4410lbs)



G20 series is light duty gate motors and support standard sliding gate with 2000kg in weight. Galvanized steel gear rack is one of the necessary for this gate motor to work.



GATECH's classic drives can meet all customer wishes and all door system needs. Its sliding gate operators system can move doors weighing up to 3,000 kg.It is the best automatic sliding door system supplier in China. A strong drive is the result of suppliers and manufacturers working together. That's why we work by the principle "our customers are like friends" every day.



GATECH automatic sliding door systems are backed by good spare parts, repair and warranty service.



Application



Remote Control AC 110v Gate Opener Electronic 2000kg Gate Mass 0

The gearbox is lubricated, and the coded remote control allows transmission of 30 to 50 meters. This sliding control panel supports photocell input to provide additional safety features, and limit switches can achieve reliable and accurate positioning. The shell is made of high-quality materials with high quality





FAQ





What is the input voltage for this gate motors ?

110V input voltage.



What is the Max weight of gate?

Max weight supporting is 2000kgs.



How many models do you have for sliding gate openers ?

G6,G8,G15,G20,G30



What is the frequncy of your remote control for this sliding gate motors?

Remote control models are 433Hz.



What is the longest remote control distance in meters?

Long range distance reach 100m.



How many gate motors can be controlled by a remote control?

4 gate motors for a remote control.



What is your MOQ?

1 set is okay. More quantity with nice discount.



What's the payment you accept?

As usual our payment is 30%T/T as deposit, and the 70% balance against the copy of B/L. Also we accept the payment such as L/C,Or PayPal.



How long is your product warranty?

24 months. Spare parts provided freely within quality warranty.



How about the delivery time?

For customized order, we can deliver in 15-25 days. It's based on what's kinds of styles and the quantity.
