27*32 Commercial Sliding Gate Opener Motor 1500kg 12 M/Min 44 IP Rating

27*32 Commercial Sliding Gate Opener Motor 1500kg 12 M/Min 44 IP Rating

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G15

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: Automatiic Sliding Gate Motor Operator Open Style: Sliding
Color: Red,Grey Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated,Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Park,Home
Usage: Factory And Dormitory Size: Width 27cmX Height 32cm
Advantage: Strong, Convenient Alarm Lighting: Optional
High Light:

27*32 Commercial Sliding Gate Opener

,

Gate Opener Motor 1500kg

,

44 IP electric sliding gate motor

Product Description

Ac 220v Single Phase 1500kg Automatic Sliding Gate Opener Commercial Use





The main part of an electric automatic sliding gate is its door motor. These door motors come in two different variants - AC and DC. The main difference is that DC motors are used for small gates with solar power, battery backup because AC motors are used for heavier gates because of their strength and longevity.



The design of the GATECH system combined with the continuous lubrication of the mechanical components ensures a very long trouble-free service life. The motor and gearing provide smooth performance in a wide variety of operating conditions.



                                                             G15  Residential use

Power Supply 220V +/- 10%, 50Hz- Single Phase
Power of motor 500W
Output Pinion 19 Tooth Mod 4
Operating Speed 12m/min
Motor Cooling Direct Drive Fan (1400RPM)
Ambient Temperature Range From-37'F (-35°C) to 149.F (+65'C)
Motor Thermal Protection Electronic
Maximum Gate length 20m
IP Rating 44
Shipping Mass of Unt 17kg(- 37Ibs)
Maximum Gate Mass 1000kgs-1500kg (2025~3307 lbs)


GATECH operators provide sliding door motors up to 1500kg in 220V and 110V versions;
G15 automatic sliding gate operator is equipped with a built-in control panel;

Built-in 433 MHZ and electromechanical or magnetic limit switch;
G15 series is heavy duty gate motors and support standard sliding gate with 1500kG in weight;

Galvanized steel gear rack is one of the necessary for this gate motor to work;





PCB inside of sliding gate motors



27*32 Commercial Sliding Gate Opener Motor 1500kg 12 M/Min 44 IP Rating 0

27*32 Commercial Sliding Gate Opener Motor 1500kg 12 M/Min 44 IP Rating 1






The gearbox is lubricated, and the coded remote control allows transmission of 30 to 50 meters. This sliding control panel supports photocell input to provide additional safety features, and limit switches can achieve reliable and accurate positioning. The shell is made of high-quality materials with high quality


FAQ


What is the input voltage for this gate motors ?
220V input voltage.

What is the Max weight of gate?
Max weight supporting is 1500kgs.

How many models do you have for sliding gate openers ?
G6,G8,G15,G20,G30

What is the frequncy of your remote control for this sliding gate motors?
Remote control models are 433Hz.

What is the longest remote control distance in meters?
Long range distance reach 100m.

How many gate motors can be controlled by a remote control?
4 gate motors for a remote control.



Can you use our brand?

Yes, we accept OEM depend on your quantities.



What's the payment you accept?

Payment<=5000USD, 100% T/T in advance. Payment>=10000USD, 30% T/T in advance ,balance against of copy of B/L.If you have another questions, pls feel free to contact us.



How long is your product warranty?

Two years when you got goods.



How about the delivery time?

For standard products, 10-25 days are available.
