Aluminum Automatic Sliding Gate Opener 250W AC Motor Sliding Gate Controller

Aluminum Automatic Sliding Gate Opener 250W AC Motor Sliding Gate Controller

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G6

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: Ac Sliding Gate Motor Kit Open Style: Sliding
Color: Red,White Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated,Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Park,Garden
Usage: Factory And House Size: Width 27cmX Height 32cm
Advantage: Strong, Trustworthiness Alarm Lighting: Optional
High Light:

Aluminum Automatic Sliding Gate Opener

,

250W Ac Motor Sliding Gate Controller

,

250W industrial sliding gate motor

Product Description

Ac 110v 600kg Automatic Door Operators Home Use



Founded in 2005, GATECH has over 15 years of experience installing thousands of systems, including driveway gates, automatic gates and electric gates for commercial and residential premises.



This operator has a compact design and is suitable for residential and light commercial use. New inductive limit switches with magnets on the rack facilitate easy installation. The control panel is designed with additional safety and ease of use in mind. The control board has specific terminals to designate stop, close safety, open safety and safety edge.



                                                             G6  Residential use

Power Supply 110V +/- 10%, 60Hz- Single Phase
Power of motor 250W
Output Pinion 19 Tooth Mod 4
Operating Speed 12m/min
Motor Cooling Direct Drive Fan (1400RPM)
Ambient Temperature Range From-37'F (-35°C) to 149.F (+65'C)
Motor Thermal Protection Electronic
Maximum Gate length 20m
IPRating 44
Shipping Mass of Unt 15kg(- 32 Ibs)
Maximum Gate Mass 600kgs (~1323 lbs)



Auto-reverse on closing if it hits an obstacle

Stopping on opening if it hits an obstacle

Control to stop immediately at any time when the gate is moving

Limit switch N.C/N.O selectable (using micro-switch)

LED indications for easy installation and fault diagnosis

Photocell Electric beam control input available

Adjustable forcing sensing trimmer



PCB inside of motor with soft start and stop



Aluminum Automatic Sliding Gate Opener 250W AC Motor Sliding Gate Controller 0Aluminum Automatic Sliding Gate Opener 250W AC Motor Sliding Gate Controller 1





The gearbox is lubricated, and the coded remote control allows transmission of 30 to 50 meters. This sliding control panel supports photocell input to provide additional safety features, and limit switches can achieve reliable and accurate positioning. The shell is made of high-quality materials with high quality





FAQ





What is the input voltage for this gate motors ?

110V input voltage.



What is the Max weight of gate?

Max weight supporting is 600kgs.



How many models do you have for sliding gate openers ?

G6,G8,G15,G20,G30



What is the frequncy of your remote control for this sliding gate motors?

Remote control models are 433Hz.



What is the longest remote control distance in meters?

Long range distance reach 100m.



How many gate motors can be controlled by a remote control?

4 gate motors for a remote control.



What is your MOQ?

One set is workable, but it is special cost for you.



What is your payment term?

Payment<=5000USD, 100% T/T in advance. Payment>=10000USD, 30% T/T in advance ,balance against of copy of B/L.If you have another questions, pls feel free to contact us.



How long is your product warranty?

2 year warranty



What is the delivery time?

For standard products, 10-25 days are available.
