550W Heavy Duty Single Slide Electric Gate Opener 1500kg

550W Heavy Duty Single Slide Electric Gate Opener 1500kg

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE
Model Number: G15

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Name: Modern Sliding Gate Motor Open Style: Sliding
Color: White ,Purple Material: Aluminum
Type: Entry Doors Feature: Waterproof
Frame Finishing: Powder Coated,Galvanized+PVC Coated Frame Material: Metal
Opening Pattern: Automatic Metal Type: Aluminum
Surface Treatment: Galvanized Application: Public Building,Farm
Usage: Garden Decoration,factory,Community Size: Width 27cmX Height 32cm
Advantage: Easy Life, Economical And Practical Alarm Lighting: Optional
High Light:

Heavy Duty Single Slide Electric Gate Opener

,

Slide Electric Gate Opener 1500kg

,

550W Heavy Duty Gate Opener 1500kg

Product Description

Ac 110v 1500kg Electric Heavy Duty Sliding Gate Operators Residential Use



The Maxi range of sliding door operators is perfect for automating heavy duty industrial doors (up to 1500 kg). The front manual release lever allows the user to manually operate the door in an emergency, such as during a power outage.

The aluminum of the gearbox housing with the galvanized iron of the motor body.

Gear reducer is highly lubricated by oil, wear of the internal mechanical components is kept to a minimum.



            Electric Heavy Duty Sliding Gate Motors G15  Residential Use

Power Supply 110V +/- 10%, 60Hz- Single Phase
Power of motor 550W
Output Pinion 19 Tooth Mod 4
Operating Speed 12m/min
Motor Cooling Direct Drive Fan (1400RPM)
Ambient Temperature Range From-37'F (-35°C) to 149.F (+65'C)
Motor Thermal Protection Electronic
Maximum Gate length 20m
IPRating 44
Shipping Mass of Unit 17kg(- 37 Ibs)
Maximum Gate Mass 1000 kgs~ 1500 kgs (2025 lbs ~ 3307 lbs)



Built-in 433 MHZ and electromechanical or magnetic limit switch;

Galvanized steel gear rack is one of the necessary for this gate motor to work;

GATECH nylon pinions are made with a special polymer formula for your extra optional;

The automatic door closing delay time is adjustable.

Control with force adjustable .

Built-in obstacle detection and overcurrent settings.



The luxury package includes:

Gear Motor, 4x Remote Controls, Safety Sensors, Directional Lights, 4M Rack and Pinion





Remote controls for sliding gate openers



550W Heavy Duty Single Slide Electric Gate Opener 1500kg 0550W Heavy Duty Single Slide Electric Gate Opener 1500kg 1

The gearbox is lubricated, and the coded remote control allows transmission of 30 to 50 meters. This sliding control panel supports photocell input to provide additional safety features, and limit switches can achieve reliable and accurate positioning. The shell is made of high-quality materials with high quality





FAQ





What is the input voltage for this gate motors ?

110V input voltage.



What is the Max weight of gate?

Max weight supporting is 1500kgs.



How many models do you have for sliding gate openers ?

G6,G8,G15,G20,G30



What is the frequncy of your remote control for this sliding gate motors?

Remote control models are 433Hz.



What is the longest remote control distance in meters?

Long range distance reach 100m.



How many gate motors can be controlled by a remote control?

4 gate motors for a remote control.



Is there a requirement for the MOQ?

One unit is available,but it is sample cost. For large quantity,Please negotiable with us.



What kind of payments do you support?

Payment<=5000USD, 100% T/T in advance. Payment>=10000USD, 30% T/T in advance ,balance against of copy of B/L.If you have another questions, pls feel free to contact us.



What is your warranty terms?

2 year warranty



How long is your delivery time?

For standard products, 10-25 days are available.
