Universal 300kg Automatic Rolling Gate Opener Residential Low Voltage

Universal 300kg Automatic Rolling Gate Opener Residential Low Voltage

Product Details:

Place of Origin: China
Brand Name: GATECH
Certification: CE,ROHS
Model Number: GR300A

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Carton package
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 sets per month
Get Best Price Contact Now

Detail Information

Type: AC Roller Shutter Motor Color: Red,Black
Phase: Three Phase,Single Phase,Single/Three-phase,Single-phase Product Name: Automatic Garage Door Opener
Warranty: 1 Year Material: Aluminium,Iron,Copper Wire,Aluminum Alloy And ABS
Application: Home Appliance,Residential Roller Garage Doors
High Light:

300kg automatic rolling gate opener

,

Automatic Rolling Gate Opener Residential

,

300kg rolling gate operators

Product Description

Universal Garage Door 300kg AC Roller Shutter Motors Home Use



GATECH is specialized in the production of rolling shutter motors and its control system.Our main lines include AC and DC rolling door motors. We have a special team, who focuseses on producing electric rolling doors more than 10 years. And we have our own marketing channel, which diversification and customer-oriented. Our products have been exported to more than 20 countries and regions in the world such as Iran, Vietnam,Brazil,India etc. Our rolling door motor has its excellent quality.



1. 100% copper material inside the motor.

2. Transmission mechanism has reasonable design, advanced technology, and specially developed grease, gear not easy wear, durable, low noise, small shaking.

3. Protective measures : Placed inside the motor overheat protector, overheating protection function.

4. Low-voltage and high-DC powermoter, low consumption;

5. Easy manual operation when power failure and it could also be equipped with electrical storage devices;

6. Limit switch unit enables precise adjustment of doors in up and down positions;

7. With convenient , stable function of remote control ,long distance remote operation is available;



Model

Rated output torque

(N.m)

Rated output speed

(r/min)

Motor power

(w)

Rated voltage

(V/Hz)

Rated current

(A)

Continuos working time(min)

Durm dube outer diameter

(mm)

Max lifting force

(kg.f)

Max lifting height

(m)

AC300-1P 225 5.4 200 220/50 2.8 8 114 300 6
AC600-1P 412 5.4 300 220/50 3.3 8 140 600 6
AC800-1P 647 4 400 220/50 4.7 8 165 800 8
AC1000-1P 809 4 400 220/50 4.9 8 165 1000 8
AC1500-1P 809 3.5 700 220/50 8.2 8 165 1500 9





Bracket for Rolling shutter motors

Universal 300kg Automatic Rolling Gate Opener Residential Low Voltage 0Universal 300kg Automatic Rolling Gate Opener Residential Low Voltage 1





FAQ





What is your MOQ?

One unit is available,but it is sample cost. For large quantity,Please negotiable with us.



What is your payment term?

For sample ,T/T in advance.For customize order,35% T/T in advance,balance before shipping.



How long is your product warranty?

Two years when you got goods.



What is the delivery time?

For item in stock, it will take 2-3days to seaport after payment.
